U8668-D User Manual

This manual provides information on the features, package contents, layout, etc. of U8668-D.

U8668-D User Manual - cover page
Brand
U8668-D
Category
Motherboard
Document type
User Manual
Language
English
Pages
71
File format
PDF
File size
988 KB
Published
06 April, 2012
Updated
30 September, 2023
MD5 checksum
4499041744A79697C6EDFD2939D7C11F
PDF
U8668-D User Manual PDF

About this manual

The U8668-D motherboard manual provides detailed information on the board's features, supported CPUs, memory specifications, expansion slots, and on‑board peripherals. It includes layout diagrams for various hardware revisions, a list of package contents, and step‑by‑step instructions for installation and BIOS configuration.

Additional sections cover troubleshooting, clearing CMOS, and BIOS setup options such as CPU clock ratio and spread spectrum control, helping users configure and maintain the system safely.

What's inside

  • Features
  • Package contents
  • Layout diagrams
  • CPU and memory specifications
  • Expansion slots
  • On‑board peripherals
  • BIOS Setup
  • Troubleshooting

Specifications

Maximum memory2 GB
ChipsetNorth Bridge P4M266A, South Bridge VT8235
PCI slotsThree 32‑bit PCI bus master slots (versions 3.x‑7.x) plus additional slots per version
AGP slotOne AGP slot
Network10/100 Mbps Ethernet (RTL8201BL or VIA VT6103/6103L)

Frequently asked questions

What is the maximum memory the board can handle?

The U8668‑D can accommodate up to 2 GB of DDR memory.
