About this manual

This manual covers everything you need to set up the KM400TA Series mainboard, including hardware installation, BIOS configuration, and software setup. It also details the supported processors, memory types, and peripheral interfaces.

Additional sections describe advanced features such as CPU Over‑Temperature Protection, Watch Dog Timer, and digital CD audio configuration for Windows operating systems.

What's inside

Getting Started
Specification
Hardware Installation
Software Setup
Troubleshooting
Appendix I: Super 5.1 Channel Setup
Appendix II: Digital CD Audio Setup

Specifications

CPU Socket	Socket 462
Supported Processors	AMD Athlon XP, Athlon, Duron, Barton
Front Side Bus Frequency	200/266/333 MHz
Chipset	VIA KT400A (Northbridge) / VIA VT8235 (Southbridge)
Memory Capacity	Up to 2 GB DDR SDRAM (unbuffered, non‑ECC)
AGP Slot	1 × 1.5 V AGP 4X/8X
USB Ports	6 × USB 1.1/2.0
LAN (PRO version)	VIA VT6103 10/100 Mbps

Frequently asked questions

Which processors are compatible with the KM400TA Series motherboard?

It supports AMD Athlon XP, Athlon, Duron, and Barton processors in Socket 462.

What operating systems can be installed on this board?

The board works with most popular Windows operating systems, including Windows 9X, ME, 2000, and XP.

How many USB ports are provided on the KM400TA Series?

The motherboard includes six USB 1.1/2.0 ports.
