This document is about the copyright and disclaimer of the product.
This manual covers the ECS P43T-A2 motherboard, a high‑performance board designed for Intel® Yorkfield/Wolfdale processors in an LGA775 socket. It details the board’s features, including the Intel Eaglelake P43 Northbridge, ICH10 Southbridge, and support for DDR2 memory up to 16 GB.
The guide includes chapters on installing the motherboard, configuring the BIOS, and using the supplied software utilities. Safety precautions, jumper settings, and driver installation procedures are also provided to help users set up and maintain the system.
| Supported FSB frequencies | 1333/1066/800 MHz |
|---|---|
| Memory type | DDR2 DIMM 800/667 MHz |
| Maximum memory capacity | 16 GB |
| SATA ports | 6 × SATA 3.0 Gb/s |
| Audio codec | 5.1 Channel High Definition Audio |
The board can accommodate up to 16 GB of DDR2 memory across four DIMM slots.
It includes six SATA ports, each supporting up to 3.0 Gb/s transfer rates.
