LCR-8101 is a digital high precision LCR meter from GW INSTEK, which can measure resistance, capacitance, inductance, frequency, phase angle and Q value.
This manual covers safety instructions, power‑up procedures, and detailed descriptions of the front and rear panels of the GWINSTEK LCR‑8101 LCR meter. It explains the main features, measurement types, and how to use the tilt stand and power settings.
Additional sections describe remote‑control interfaces (GPIB, RS‑232C), command syntax, calibration, accuracy charts, and compliance declarations. The appendix includes fuse replacement instructions, accuracy definitions, and an index for quick reference.
| Test frequency range | 20 Hz ~ 1 MHz |
|---|---|
| Measurement resolution | 6 digits |
| Drive level | 10 mV ~ 2 V |
| Basic measurement accuracy | ±0.1 % |
| LCD display resolution | 320 × 240 pixels |
| AC input voltage | 115 V / 230 V, 50/60 Hz |
| Fuse type | T3A/250 V |
| Maximum number of multi‑step programs | 64 programs, up to 30 steps each |
The instrument accepts 115 V or 230 V AC input at 50 Hz or 60 Hz.
The basic measurement accuracy is ±0.1 %.
A T3A/250 V fuse is required.
Yes, it supports GPIB (24‑pin female) and RS‑232C (DB‑9 male) remote‑control interfaces.
