This document provides information on the precautions to be taken when installing an AGP card, particularly ensuring that the card's specification is AGP 4X(1.5V) and not AGP 2X. It also mentions some examples and reminds to remove the Dual BIOS sticker before installing a PCI device.
This manual provides step‑by‑step instructions for installing the GA‑8PE800 Ultra/Pro(-R) motherboard. It explains the required AGP slot (AGP 4X 1.5 V) and warns against using incompatible AGP 2X slots, as well as detailing the layout of the board and the connection of power, IDE, SATA, and other cables.
The guide also covers BIOS setup, including standard CMOS settings and advanced options, and lists the accessories supplied with the board. Contact information for Gigabyte’s global support centers is included for technical assistance. This manual is written in Chinese.
| AGP slot type | AGP 4X 1.5 V |
|---|---|
| Motherboard model | GA-8PE800 Ultra/Pro(-R) |
Use the AGP 4X 1.5 V slot; AGP 2X slots are not supported and may prevent the system from booting.
No, removing the stickers may affect the product’s warranty.
