This manual describes the installation and use of the GA-8IG1000 Pro-G/GA-8IG1000-G/GA-8IG1000 mainboard.
This manual covers the GA-8IG1000 motherboard, a P4‑based board that supports Intel® Pentium® 4 processors, the Intel 865G chipset, and a range of memory and I/O options. It includes a layout diagram, component descriptions, and a full list of specifications such as supported CPUs, memory types, and expansion slots.
The guide walks users through installing the CPU, memory modules, and expansion cards, configuring BIOS settings, and connecting power, audio, and peripheral interfaces. It also contains FCC compliance information, troubleshooting tips, and contact details for Gigabyte support. This manual is written in Chinese.
| CPU Socket | Socket 478 |
|---|---|
| Supported CPUs | Intel® Pentium® 4 (Northwood, Prescott) with HT |
| Chipset | Intel 865G |
| Memory Slots | 4 × 184‑pin DDR DIMM (DDR400/DDR333/DDR266) |
| AGP Slot | AGP 8X/4X (1.5 V) |
| IDE Interfaces | 2 IDE bus masters (UDMA 33/ATA 66/ATA 100) |
The GA-8IG1000 uses a Socket 478 for Intel Pentium 4 processors.
It is equipped with the Intel 865G chipset.
The board provides four 184‑pin DDR DIMM slots supporting DDR400, DDR333, and DDR266 modules.
There is one AGP slot supporting 8X/4X operation at 1.5 V.
