Sanyou Frequency Rate Turn Speed Line Speed Table User Manual

Frequency, speed and line speed meter operation manual, introduces the use method, installation method, precautions and other contents of the product

Brand: Sanyou
Document type: User Manual
Language: Chinese
Pages: 2
File format: PDF
File size: 144 KB
Published: 06 April, 2012
Updated: 30 September, 2023
MD5 checksum: F0A739B9B62548B5A97A8348515E3FE1
PDF: Sanyou Frequency Rate Turn Speed Line Speed Table User Manual PDF

About this manual

This manual introduces the Sanyou frequency, turn‑speed and line‑speed meter, covering safety precautions, power requirements and basic operation. It explains how to connect the device, clean the controller safely, and avoid damage by using the specified voltage.

The document details display options, alarm configuration, coefficient and unit settings, and measurement methods for frequency, speed and line speed. Example applications and communication protocol notes are also provided. This manual is written in Chinese.

What's inside

Safety Instructions
Power Supply and Wiring
Display Options
Parameter and Coefficient Settings
Alarm Configuration
Measurement Methods
Application Example
Warranty and Support

Specifications

Input voltage (DC)	24 V DC
AC voltage range (default)	90‑260 V AC
Operating temperature	0‑50 °C
Relative humidity	35‑85 %

Frequently asked questions

What power supply should be used for the meter?

The device should be powered with a 24 V DC supply and must not be connected to other voltages.

How should the controller be cleaned?

Disconnect the power before cleaning the controller to avoid damage.

How are alarm thresholds set?

Select the alarm channel (AL1, AL2, AL3), set the lower and upper limits within the allowed range, and confirm with the SET key.
