Foxconn NF4K8AC/NF4UK8AC Motherboard User Manual

This is a Chinese user manual for NF4K8AC/NF4UK8AC series mainboards.

Foxconn NF4K8AC/NF4UK8AC Motherboard User Manual - cover page
Brand
NF4K8AC/NF4UK8AC
Category
Motherboard
Document type
User Manual
Language
Chinese
Pages
53
File format
PDF
File size
12.1 MB
Published
05 April, 2012
Updated
30 September, 2023
MD5 checksum
8FE67F750C43490B76DED1BE0DC88DEA
PDF
Foxconn NF4K8AC/NF4UK8AC Motherboard User Manual PDF

About this manual

This manual provides the necessary information for installing, configuring, and safely operating the Foxconn NF4K8AC/NF4UK8AC series motherboard. It includes declarations of conformity to EMC and FCC standards, safety notices, and hardware identification.

The document also describes the motherboard's LAN interface, supported utilities, and component references such as the Silicon Image PAD3 controller. Technical limits for input current and electromagnetic emissions are listed to ensure compliance with regulatory requirements. This manual is written in Chinese.

What's inside

  • Declaration of Conformity
  • Safety Information
  • Hardware Overview
  • LAN Configuration
  • Super Utility Features
  • Regulatory Compliance

Specifications

Maximum input current per phase≤ 16 A
LAN port speed10/100 Mbit/s
FCC classificationClass B Subassembly
Silicon Image controllerPAD3

Frequently asked questions

What LAN speeds are supported by the motherboard?

The motherboard provides a 10/100 Mbit/s Ethernet interface.

Download PDF (12.1 MB)
