This manual is a description of the product GA-8I845GV / GA-8I845GV-C from G.B.T. Technology Träding GMbH, which introduces the features and characteristics of the product.
This manual explains how to install and configure the Gigabyte GA-8I845GV (and GA-8I845GV-C) motherboard. It includes detailed diagrams of the board layout, descriptions of the CPU socket, memory slots, expansion slots, and I/O connectors, as well as step‑by‑step instructions for installing the processor, memory, and peripherals.
The guide also covers BIOS configuration, supported hardware specifications, compliance with EMC and safety directives, and provides contact information for Gigabyte technical support worldwide. This manual is written in Chinese.
| Form factor | Micro ATX |
|---|---|
| CPU socket | Socket 478 |
| Supported CPUs | Intel Pentium 4 (Celeron, Willamette, Northwood) |
| Chipset | Intel 845GV |
| Audio codec | Realtek ALC655 |
| LAN controller | Realtek RTL8100C |
| IDE ports | 2 IDE bus master (UDMA 33/ATA 66/ATA 100) |
It uses a Socket 478 for Intel Pentium 4 processors.
The board includes a Realtek ALC655 audio codec.
