This document is the user manual for GIGABYTE GA-8I875 / GA-8IK1100 motherboard, mainly introduces the specifications, functions and installation instructions of the motherboard.
This guide provides step‑by‑step instructions for installing the GA‑8I875 and GA‑8IK1100 motherboards, including layout diagrams, connector locations, and BIOS configuration. It also lists the supported CPUs, memory types, and expansion slots.
Compliance information, safety notices, and contact details for Giga‑Byte support are included, along with a glossary of abbreviations used throughout the manual. This manual is written in Chinese.
| CPU Socket | 478 |
|---|---|
| Supported CPUs | Intel® Pentium® 4 (Northwood, Prescott) with HT |
| Chipset | Intel® 875P HOST/AGP/Controller |
| AGP Slot | AGP Pro 8X/4X (1.5 V) |
| PCI Slots | 33 MHz PCI 2.3 compliant, multiple slots |
| SATA Ports | Supports RAID0 striping and RAID1 mirroring |
| USB Ports | USB 2.0/1.1 (4 ports) |
| IEEE‑1394 | FireWire (IEEE1394) support |
The board uses the Intel® 875P HOST/AGP/Controller chipset.
