The SHK‑XHG series provides arc‑quenching, harmonic elimination, line selection and over‑voltage protection for 3 ~ 35 kV three‑phase ungrounded power systems. It uses patented technologies to quickly detect and isolate single‑phase ground faults, limit over‑voltages, and record fault events.
The manual describes the device’s main components, optional functions, technical parameters, mechanical dimensions, environmental limits, ordering information, and procedures for installation, commissioning, and maintenance. This manual is written in Chinese.
| Rated Voltage | 7.2 kV, 12 kV, 40.5 kV |
|---|---|
| Rated Current | 50 A‑315 A (multiple options) |
| Breaking Capacity of High‑Voltage Limiting Fuse | 63 kA ~ 160 kA |
| Breaking Time of High‑Voltage Limiting Fuse | 1 ~ 2 ms |
| Reference Size (35 kV cabinet) | 1800 mm × 2800 mm × 2800 mm (W × D × H) |
| Operating Temperature (indoor) | -15 °C ~ +60 °C (special: -30 °C ~ +60 °C) |
| Maximum Altitude | 1000 m (special up to 4000 m) |
The device is available with rated voltages of 7.2 kV, 12 kV, or 40.5 kV.
The fuse can interrupt currents up to 63 kA ~ 160 kA.
Its opening time is typically between 1 ms and 2 ms.
The cabinet measures 1800 mm × 2800 mm × 2800 mm (W × D × H).
