The Kitrol Kinvet-F series variable frequency drive is designed for high‑speed control of three‑phase induction motors in industrial applications. It offers a range of power ratings from 1.5 kW to 45 kW and supports multiple control functions such as start‑stop, speed ramp, and braking.
The manual covers safety warnings, installation environment requirements, detailed wiring diagrams for power and control circuits, operation of the front panel, parameter configuration, fault diagnosis, and example applications. Appendices include the MODBUS protocol and custom communication settings. This manual is written in Chinese.
| Model Type | KHF-4T22K |
|---|---|
| Input Voltage | 3‑phase 380 V 50/60 Hz |
| Rated Output Power | 22 kW |
| Rated Output Current | 45 A |
| Serial Number Example | AKD1234567697 |
