This document is a washing machine user manual, which introduces the washing machine's use method, function, operation steps, etc.
This manual explains how to install the Whirlpool AW043638 front‑load washing machine, connect water and power, and set up the transport bolts. It also details the control panel functions, including program selector, start/pause, variable spin, and start‑delay settings.
Performance data for each wash program, water‑pressure requirements, spin‑speed limits, and safety features such as automatic diagnostics are listed. Maintenance sections cover filter cleaning, draining residual water, and troubleshooting common issues. This manual is written in Chinese.
| Maximum spin speed (cotton program) | 900 rpm |
|---|---|
| Reduced spin speed (delicate program) | 400 rpm |
| Water pressure range | 100‑1000 kPa (1‑10 bar) |
| Machine weight | 75 kg |
Press the Start Delay button and rotate to select a delay of 1‑23 hours; the chosen time is shown on the display.
After pressing the Start/Pause button, hold the Reset button for 3 seconds; the start‑delay time disappears from the display.
Open the filter compartment, remove the filter, clean any debris, and reinstall it as described in the “Cleaning the filter” section.
The cotton program limits spin speed to 900 rpm to protect garment quality.
