This document describes the features and specifications of the Mitsubishi FR-D700 series inverter. The series inverter is characterized by high reliability, safety stop function, and powerful functions and performance. It can be widely used in transfer machines, elevators, washing machines, agitators, and other equipment that require high starting torque.
The FR‑D700 series is a three‑phase inverter designed for industrial motor applications such as conveyors, hoists, pumps and washing machines. It complies with the EU Machinery Directive and includes built‑in safety functions like an emergency stop.
The document covers wiring with spring‑clamp terminals, parameter setting via RS‑485, communication protocols (Modbus RTU, Mitsubishi protocol), cooling‑fan life, protective functions, and detailed mechanical and electrical specifications. Optional accessories such as parameter units and enclosure panels are also described.
| Model | FR-D700 |
|---|---|
| Rated capacity (kVA) | 0.3 – 3.8 |
| Input voltage | Three‑phase 380‑480 V, 50/60 Hz |
| Output frequency range | 0.2 Hz to 400 Hz |
| Cooling fan design life | 10 years |
| Wiring method | Spring clamp terminals, wire up to 1.5 mm diameter |
| Protective structure | Enclosed type (IP20) or IP40 for totally enclosed |
| Communication protocols | Modbus RTU, Mitsubishi inverter protocol |
Spring‑clamp terminals allow wires up to 1.5 mm diameter to be inserted directly without a separate bar terminal.
The cooling fan is rated for a design life of 10 years.
The FR‑D700 supports Modbus RTU and the Mitsubishi inverter protocol.
