The ADV7151 is a CMOS monolithic video RAM‑DAC that provides 10‑bit pseudo‑color graphics output up to 220 MHz. It integrates three 10‑bit video D/A converters, palette RAM, and a programmable MPU interface for high‑performance color workstations.
The document includes full electrical specifications, timing characteristics, recommended operating conditions, absolute maximum ratings, and thermal/packaging information for the 100‑lead plastic QFP version of the device.
| Resolution (Each DAC) | 10 Bits |
|---|---|
| Input High Voltage (Digital Inputs) | 2 V min |
| Ambient Operating Temperature | 0 °C to +70 °C |
| White Level Output Current | 17.69 mA min |
The device supports a maximum pixel clock rate of 220 MHz.
The recommended operating temperature range is 0 °C to +70 °C.
The ADV7151 is powered from a 5 V nominal supply (4.75 V to 5.25 V allowed).
It is supplied in a 100‑lead plastic quad flatpack (QFP).
