This manual contains detailed instructions and precautions on how to operate and use this equipment. For your safety and benefits, please read this manual carefully before using this equipment. Please place the manual beside the equipment for easy reading for quick reference.
This manual provides detailed instructions for safely operating the Gestetner CP6451C digital press. It includes safety warnings, power requirements, and step‑by‑step procedures for preparing media, adjusting image settings, and running standard, color, and halftone prints.
The document also lists the technical specifications of the machine, such as print speed, paper size limits, tray capacities, and physical dimensions, helping users understand the capabilities and limits of the equipment. This manual is written in Chinese.
| Printing Process | Fully automatic single‑cassette system |
|---|---|
| Maximum Original Size | 300 mm × 432 mm (11.8" × 17.0") |
| Pixel Density | 400 dpi × 400 dpi |
| Print Speed | 60 – 120 rpm (5‑step) |
| Paper Weight Range | 47.1 g/m² – 209.3 g/m² (12.5 lb – 55.6 lb) |
| Input Tray Capacity | 1,000 sheets (80 g/m²) |
| Output Tray Capacity | 1,000 sheets (80 g/m²) |
| Dimensions (W×D×H) without feeder | 805 mm × 705 mm × 640 mm |
| Power Supply | 220‑240 V, 50/60 Hz, 1.7 A or higher |
It requires a 220‑240 V power supply at 50 or 60 Hz, drawing at least 1.7 A.
The input tray can hold up to 1,000 sheets of 80 g/m² paper.
The maximum paper size is 300 mm × 432 mm (11.8" × 17.0").
