Sampo AU-J45DC+AM-J45DC Air Conditioner User Manual

Brand: Sampo
Category: Air conditioner
Document type: User Manual
Language: Japanese
Pages: 24
File format: PDF
File size: 1.5 MB
Published: 27 March, 2012
Updated: 31 May, 2012
MD5 checksum: 1453E8104B7F92AF69DCB2EC9235A815
PDF: Sampo AU-J45DC+AM-J45DC Air Conditioner User Manual PDF

About this manual

This manual provides safety precautions, installation guidelines, and operating instructions for the Sampo AU-J45DC (indoor) and AM-J45DC (outdoor) air‑conditioning units. It includes details on wiring, grounding, battery handling, and troubleshooting steps.

Technical specifications such as cooling capacity, power consumption, dimensions, weight and refrigerant type are listed, along with recommended maintenance practices and emergency procedures. This manual is written in Japanese.

What's inside

Precautions Before Use
Installation Guidelines
Operation Controls
Battery Replacement
Troubleshooting
Technical Specifications

Specifications

Cooling Capacity	18000 BTU(C)
Power Supply	220‑240V, 60Hz
COP (Energy Efficiency Ratio)	3.19 (3.0‑4.1)
Indoor Unit Dimensions (H×W×D)	265 mm × 795 mm × 200 mm
Refrigerant	R‑410A (0.85 kg)

Frequently asked questions

What should I do if I notice a burning smell while the unit is operating?

Stop the operation immediately and contact the service dealer.

Can I replace the battery myself?

Battery replacement must be performed by qualified service personnel.

Do I need to connect a grounding wire during installation?

Yes, a grounding wire must be properly connected.

What voltage should be used for the indoor unit power supply?

Use a 220‑240 V, 60 Hz power source.
