The document describes the features and characteristics of the AMD 580X CrossFire mainboard, including the compatible AMD Soc AM2 processors and 940-pin socket.
This manual covers everything needed to set up and operate the AMD 580X CrossFire mainboard, including package contents, hardware specifications, system block diagram, and optional accessories such as the Thermo Stick. Detailed sections guide you through CPU installation, jumper settings, memory configuration, rear I/O ports, and internal connectors.
Additional chapters describe BIOS setup options, utility and driver installation, Ghost BIOS recovery procedures, and a comprehensive appendix of hotkey functions. The document also lists technical specifications and provides troubleshooting tips for common issues.
| Processor Support | Socket‑AM2 (940‑pin) AMD Athlon‑X2/Athlon‑64/Sempron |
|---|---|
| Chipset | AMD 580X CrossFire (580X + SB600) |
| Memory Slots | Four 240‑pin unbuffered non‑ECC DDR2 SDRAM DIMM sockets |
| Maximum Memory | 16 GB |
| PCI‑Express Slots | Two PCI‑E (x1) and two PCI‑E (x16) connectors |
| USB Ports | Ten USB 2.0 connectors |
| LAN | One Gigabit Ethernet (Marvell 88E8056) |
| Audio | 8‑channel Realtek ALC8xx HD audio codec |
