DM160128A is a graphic dot matrix LCD display, which is mainly composed of row driver/column driver and 160× 128 full pixel LCD display. It can complete graphic display and also display 10× 8 (16× 16 dot matrix) Chinese characters.
This document provides an overview of the DM60128A graphic LCD module, including its physical dimensions (129 mm × 102 mm × 12.8 mm), dot resolution (160 × 128) and electrical requirements such as a +5 V supply. It also lists the main hardware components and the external interface signals needed to connect the module to a controller.
Detailed sections cover the pin‑out table, timing diagrams for the T6963C controller, command set, register settings, and power‑consumption characteristics. The manual is intended for engineers integrating the module into embedded systems and includes step‑by‑step procedures for writing data and controlling display modes. This manual is written in Japanese.
| Resolution | 160 × 128 dots |
|---|---|
| Supply voltage (VDD) | +5 V |
| Operating temperature range | -10 °C to +55 °C |
| Storage temperature range | -20 °C to +70 °C |
| Module dimensions | 129.0 mm × 102.0 mm × 12.8 mm |
| Dot pitch | 0.58 mm × 0.58 mm |
| Typical supply current (active) | 3 mA – 6 mA |
| Typical supply current (standby) | 3 µA |
The display has a resolution of 160 columns by 128 rows (160 × 128 dots).
It operates from a +5 V supply (VDD).
The module measures 129.0 mm × 102.0 mm × 12.8 mm.
The module works from –10 °C up to +55 °C.
