K8T890M2AB series motherboard manual, introduces the functions and features of the motherboard, installation and use methods and other information.
This manual describes the features, hardware layout, and installation procedures for the Foxconn K8T890M2AB ATX motherboard. It includes safety notices, product specifications, and detailed instructions for BIOS configuration and driver installation.
Key sections cover BIOS password options, driver CD contents, hardware connectors, and troubleshooting tips, helping users set up and maintain the system safely and efficiently. This manual is written in Chinese.
| Form factor | ATX (305mm x 201mm) |
|---|---|
| CPU socket | Socket AM2, supports AMD Athlon 64/64X2, FX, Sempron |
| Chipset | VIA K8T890 northbridge, VT8237A southbridge |
| Memory slots | 2 DDR2 240‑pin slots, dual‑channel up to 2 GB |
| USB ports | 8 USB 2.0 ports (hot‑plug capable) |
| SATA interface | 2 SATA ports, 150 MB/s, supports RAID 0/1/0+1/JBOD |
| LAN | Optional 10/100 Mbps (L) or 10/100/1000 Mbps (K) Ethernet |
Insert the supplied driver CD, let it auto‑run, and follow the on‑screen prompts to install the VIA Chipset Driver, Realtek Audio Driver, Realtek LAN Driver, and optional applications.
