This document is the EMC certificate for P5I945P(L)(G)
This manual covers safety precautions and proper handling of the P5I945P(L)G motherboard, including static‑protection measures, power‑off requirements, and careful component insertion before installation. It also details the step‑by‑step installation process for the CPU, memory, and expansion cards.
The document lists the board’s technical features such as ATX form factor, Intel LGA775 CPU support, DDR2 memory configurations, audio channels, USB ports, LAN options, and PCI/PCI‑Express slots, providing the necessary information for system builders and technicians. This manual is written in Chinese.
| Form factor | ATX, 305 mm × 244 mm |
|---|---|
| CPU socket | Intel LGA775 |
| Memory type | DDR2 400/533/667 MHz, dual‑channel |
| Maximum memory | 4 GB |
| Audio channels | 6‑channel (6A) or 8‑channel (8A) high‑definition audio |
| Audio channels (8A) | 8‑channel high‑definition audio |
| PCI slots | 3 × PCI 2.3 slots |
| PCI‑Express slots | 2 × PCI‑Express 1.0a x1, 1 × PCI‑Express 1.0a x16 |
| USB ports | 8 × USB 2.0 ports |
Handle the board in an anti‑static bag, avoid touching component leads, disconnect power for at least 30 seconds, and keep the work area dry and static‑free.
It provides eight USB 2.0 ports.
Depending on the model, it offers either 6‑channel or 8‑channel high‑definition audio.
