W2286L and W2486L are a series of monitors, the main features are LED backlight, rotatable screen, support D-sub, DVI and HDMI interface
This manual begins with important safety precautions, explaining how to handle the power cable, avoid electric shock, and keep the monitor away from water and high‑temperature environments. It also covers cleaning, repackaging, and disposal instructions to ensure safe long‑term use.
The second part details installation and connection procedures, including how to attach the base, adjust the tilt angle, connect D‑sub, DVI‑D, HDMI and audio cables, and select supported display modes. Ergonomic recommendations and indicator‑light meanings are also described. This manual is written in Chinese.
| Tilt range | 2 ~ 15° |
|---|---|
| Recommended ergonomic tilt | ≤ 5° |
| Supported display mode 480P | 31.50 kHz line, 60 Hz field |
| Indicator LED (on) | Red |
Turn off the monitor first, then use a soft, dry cloth to wipe the screen; do not spray liquids directly onto the display.
Use the power cable supplied with the monitor; if a different cable is used, it must meet the relevant national standards.
The monitor can be tilted between 2 and 15 degrees, but for ergonomic comfort the front tilt should not exceed 5 degrees.
The manual lists several modes, for example 480P at 31.50 kHz line frequency and 60 Hz field frequency, as well as 720P, 1080i, and 1080P options.
