CMV-942A is a 19-inch TFT LCD monitor with a smart, microprocessor-based, ergonomic design that is compatible with most analog RGB (red, green, and blue) display standards, including PS/V, PS/2, Apple Macintosh Centris optional, Quadra, and Macintosh II family signals. This LCD monitor can display clear and vivid color graphics, including VGA, SVGA, XGA, SXGA (non-interlaced) and most color display cards compatible with Macintosh.
This manual covers the CHIME! CMV-942A 19" TFT‑LCD monitor. It includes quick‑setup instructions, power and safety guidelines, and detailed technical specifications such as supported video modes and electrical requirements.
The document also lists compliance certifications and provides troubleshooting tips for common display issues.
| Screen Size | 19" TFT LCD |
|---|---|
| Contrast Ratio | 1000:1 |
| Viewing Angle | 160° H / 160° V |
| Power Input | 100‑240 V AC |
| Frequency | 50/60 Hz |
| Maximum Resolution | 1280 × 1024 @ 75 Hz |
| Brightness | 300 cd/m² |
The monitor operates on an AC input of 100‑240 V.
The contrast ratio is specified as 1000:1.
The display provides a 160° horizontal and 160° vertical viewing angle.
