This manual provides an overview of the TCL LCD television, including its high‑resolution display, dual TV/monitor functionality, and energy‑saving features. It describes the available input ports (HDMI, VGA, AV, USB, etc.) and the remote‑control operation range.
The guide also covers safety precautions, installation steps, basic operation, and a troubleshooting section that addresses common issues such as weak signal, remote‑control range, and screen cleaning. This manual is written in Chinese.
| Maximum Resolution | 1920x1080 |
|---|---|
| Best Working Resolution | 1920x1080@60Hz |
| Dot Pitch | 0.46125mm x 0.46125mm |
| Viewable Area | 885.6mm x 498.15mm |
| Input Power | 220V~50Hz |
| Speaker Power | 6W+6W |
| Unpacked Dimensions | 979mm x 640mm x 106.5mm |
| Unpacked Weight | ≈16.5 kg |
| Color Gamut | 16.7 million colors |
| Remote Control Range | ≈8 m + 30° |
Use a dry, soft cloth or a cleaning solution made for LCD screens, and do not apply pressure or use water or chemical cleaners.
Unplug the 220 V power cord after turning the TV off, especially if it will not be used for more than an hour.
