This manual guides users through safe installation, basic operation, and advanced features of TCL's 4‑model LCD television series. It includes safety notices, product specifications, remote‑control usage, menu navigation, and troubleshooting tips.
Key sections cover safety warnings, model‑specific technical specifications, front‑panel diagrams, remote‑control instructions, encryption‑card setup, supported signal formats, basic operation procedures, main menu functions, system settings, media center usage, and fault analysis. This manual is written in Chinese.
| Screen diagonal | 101.8 cm (L40X10FDE), 106.7 cm (L42X10FDE), 116.8 cm (L46X10FDE), 139.7 cm (L55X10FDE) |
|---|---|
| Audio output power (left+right speakers) | 8 W + 8 W for all models |
| Working voltage | 220 V ~ 50 Hz |
| Weight | 15 kg (L40X10FDE), 23 kg (L42X10FDE), 28 kg (L55X10FDE) |
| Operating temperature | 5 °C ~ 35 °C |
| Operating humidity | 20 % ~ 80 % |
Verify that the household fuse and circuit breaker are normal, the power switch is on, and the signal cable connections are secure.
