This manual covers the safety precautions required when handling the Sampo LX-UM281 ceiling light, including keeping power off during installation, avoiding direct contact with the light source, and ensuring proper grounding. It also lists the supplied accessories and the recommended T5 28N/T5 28M lamp tubes.
Installation instructions describe how to mount the fixture to the ceiling, connect the power wires, and adjust the reflector. The troubleshooting section explains how to check wiring, replace the lamp, and what to do if a burning smell or abnormal operation is detected, with contact information for Sampo service support. This manual is written in Chinese.
| Operating Voltage | AC 110V/220V 50/60Hz |
|---|---|
| Dimensions (L×W×H) | 1900 mm × 135 mm × 85 mm |
Turn off the power supply, keep the fixture unpowered while mounting, avoid touching the lamp when hot, and ensure the fixture is grounded if it has a grounding wire.
Fix the mounting brackets to the ceiling, connect the power wires as shown, attach the reflector, and secure the lamp tube according to the instructions.
The manual recommends using T5 28M or T5 28N lamp tubes for optimal lighting performance.
Immediately disconnect the power, stop using the fixture, and contact Sampo service at 04‑2236‑6157 for assistance.
