This document introduces the use of Samsung digital LED LCD TV, including precautions for displaying static images, maintenance, and safety instructions.
This manual provides step‑by‑step instructions for installing, connecting, and operating the Samsung UA55B7000 liquid‑crystal television. It includes safety warnings, remote‑control usage, menu navigation, and guidance for attaching accessories such as the antenna isolator and wall‑mount hardware.
The document also lists the TV’s technical specifications, including display size, resolution, brightness, contrast, audio output, dimensions, weight, and environmental operating ranges, helping users understand the capabilities and proper handling of the unit. This manual is written in Chinese.
| 最佳分辨率 | 1920 × 1080 @ 60 Hz |
|---|---|
| 亮度 | ≥ 350 cd/m² |
| 对比度 | ≥ 150:1 |
| 可视角水平 | ≥ 85° |
The remote works up to 7 meters away from the television.
Use an HDMI cable thinner than 14 mm for the ultra‑thin TV model.
Connect plug 2 of the isolator to the TV’s ANT port and plug 1 to the cable‑TV line, then secure the isolator as shown.
Unplug the TV, use a dry soft cloth without solvents, and avoid covering ventilation slots.
