The ANN AM-110 is a compact, lightweight voice recorder designed for easy portability and reliable audio capture. It features automatic power‑off, voice‑activated recording, and support for external microphones and USB storage.
The manual covers safety precautions, proper battery installation, detailed button functions, recording and playback procedures, phone‑call recording setup, and a troubleshooting guide. Technical specifications such as recording time, storage capacity, and connector types are listed at the end of the document. This manual is written in Chinese.
| Model | AM-110 |
|---|---|
| Recording time (HQ mode) | 15 hours |
| Recording time (LP mode) | 18 hours |
| Storage capacity | 64 MB |
| USB interface | USB Type‑C |
| Speaker size | 20 mm diameter, 8 Ω |
| Dimensions (W×H×D) | 33×111.7×15.5 mm |
| Weight (excluding battery) | 37 g |
| Battery type | 2 × AAA alkaline batteries |
In HQ mode the recorder can record for up to 15 hours on two AAA alkaline batteries.
The recorder supports a USB flash drive, a 3.5 mm external microphone, and a 3.5 mm headphones.
