This manual covers the key features of the Haier dishwasher, safety precautions, installation steps, program selection, and regular maintenance. It also includes a detailed parts list, wiring diagram, and technical specifications.
The document guides users on proper loading of dishes, use of dedicated detergent, and how to handle common issues such as water pressure problems, drainage blockages, and error codes, with contact information for Haier service centers. This manual is written in Chinese.
| Power supply | AC 220V/50Hz |
|---|---|
| Wash pump power | 150W |
| Heater power | 1500W |
| Maximum power consumption | 1650W |
| Water consumption (standard wash) | 10 L |
| Standalone dimensions (W×D×H) | 450 × 520 × 800 mm |
| Weight | ≈85 kg |
Installation must be performed by a professional, connecting the water inlet to a suitable valve, securing the drain pipe, and ensuring enough clearance for the door to open fully.
Pull up the filter handle, remove the filter assembly, rinse it with tap water, and reinstall it.
