DSO-2090 USB Oscilloscope User Manual

DSO-2090 USB Manual is a user manual for DSO-2090 USB instrument, including warranty information

DSO-2090 USB Oscilloscope User Manual - cover page
Brand
DSO-2090
Category
Other Electronics
Document type
User Manual
Language
English
Pages
17
File format
PDF
File size
373 KB
Published
20 March, 2012
Updated
30 September, 2023
MD5 checksum
FA3E490F95CC0CAD26EFFC9D6E1F5642
PDF
DSO-2090 USB Oscilloscope User Manual PDF

About this manual

This manual covers safety precautions, handling guidelines, and maintenance for the DSO-2090 USB portable oscilloscope. It also details the hardware specifications, system requirements, and software installation process.

Additional sections explain driver installation, probe calibration, and warranty terms, helping users set up and operate the device safely and efficiently.

What's inside

  • Certificate of Product Warranty
  • Precautions for Safety
  • Handing Precautions
  • Maintenance and Storage
  • Minimum System Requirements
  • Hardware Specification
  • Dimensions
  • Software Installation
  • Driver Installation
  • Probe Calibration and Compensation

Specifications

Realtime sampling rate100 MS/s (single channel), 50 MS/s (dual channel)
Analog bandwidth40 MHz
Vertical resolution8 bits per channel
Input voltage protection35 Vpk (DC + peak AC < 10 kHz)
Display modesY‑T, X‑Y
Buffer size10 K – 64 K samples
Power sourceBus‑powered from USB, no external supply

Frequently asked questions

What is the warranty period for the DSO-2090?

The product warranty covers a period of one year from the date of purchase.

How is the DSO-2090 powered?

It is powered via the USB connection and does not require an external power source.

What are the minimum system requirements to run the DSO-2090 software?

Windows 98/ME/2000/XP/VISTA, 128 MB memory, DirectX‑supported graphics card, 800×600 resolution, 16‑bit colour depth.
