This manual covers safety precautions, proper installation spacing, and wiring requirements for the LG WD800(MG-5510SD) microwave oven. It also explains how to use the microwave, grill, and defrost functions, including recommended cooking containers and temperature settings.
Additional sections describe cleaning procedures, maintenance tips, warranty information, and contact details for service support. Technical specifications such as power output, dimensions, and weight are listed for reference. This manual is written in Chinese.
| Input voltage | 220V 50Hz |
|---|---|
| Microwave output power | 800W |
| Microwave frequency | 2450MHz |
| Overall dimensions | 512 mm (W) × 310 mm (H) × 408 mm (D) |
| Cavity dimensions | 337 mm (W) × 202 mm (H) × 373 mm (D) |
| Grill power | 1280W |
| Total capacity | 25 L |
| Usable cavity volume | 19 L |
| Net weight | ≈17 kg |
| Gross weight | ≈19 kg |
Unplug the power plug from the household 220 V outlet, then plug it back in.
