This manual explains how to safely assemble the Sampo SK‑CD12(Y) electric fan, including base installation, wiring, and securing the fan grille. Detailed step‑by‑step instructions with diagrams guide the user through connecting the power cord, attaching the base, and fixing the protective mesh.
The document also describes the fan's operation controls, such as the three‑speed selector and tilt function, and lists the technical specifications: 110 V / 60 Hz, 55 W power consumption, dimensions 382 × 200 × 365 mm, and weight 2.7 kg. This manual is written in Japanese.
| Input Voltage | 110 V / 60 Hz |
|---|---|
| Power Consumption | 55 W |
| Dimensions (W×D×H) | 382 mm × 200 mm × 365 mm |
Use the speed selector switch to choose among three speed settings; turn the knob to the desired position and the fan will run at that speed.
Immediately disconnect the power cord, do not attempt self‑repair, and contact customer service for assistance.
