The SK-CH14T electric fan operates on AC110V/60Hz with a power consumption of 55 W and measures W620 × D178 × H426 mm. It provides three wind‑speed settings (weak, medium, strong) selectable via the wind‑speed key, a timer function for 1‑3 hours, and an oscillation control.
The manual outlines safety precautions such as using only 110 V power, keeping fingers away from the grille, and avoiding use near water or unstable surfaces. It also details the step‑by‑step assembly process, including base attachment, rear‑grid installation, and front‑grid mounting before first use. This manual is written in Chinese.
| Power Supply | AC110V/60Hz 55W |
|---|
Press the power (关) key and the fan will stop rotating.
Rotate the timer knob to select 1, 2, or 3 hours; the fan will automatically shut off when the set time expires.
Use only 110 V power, keep fingers away from the grille, do not place the fan near water or on unstable surfaces, and stop use if abnormal vibration occurs.
