This file is a user manual for a product, which contains information such as product features, appearance, model, and technical specifications.
This user manual introduces the F2000-6 series frequency transformer, covering product overview, technical specifications, installation wiring, and basic operation procedures. It also details safety precautions, environmental requirements, and recommended maintenance practices.
Additional sections include function parameters, fault handling, appendices with communication manuals, function‑code quick reference tables, and warranty information, helping users configure and service the inverter safely and efficiently. This manual is written in Chinese.
| Output voltage range | 3‑phase 0‑380 V, single‑phase 0‑220 V |
|---|---|
| Frequency range | 0.00‑650.00 Hz |
| Carrier frequency | 2000‑10000 Hz |
| Control mode | SVYC (open‑loop vector) and VAF |
| Overload capacity | 150 % of rated current for 60 s |
| Ambient temperature range | -10 °C to +50 °C |
| Vibration intensity limit | 0.5 g |
| Maximum installation altitude | Below 1000 m |
| Compatible motor power | 0.4‑400 kW |
