This manual provides step‑by‑step instructions for assembling the SK‑B14LT (35 cm) and SK‑A16LT (40 cm) electric fans. It explains how to correctly attach the front and rear nets, install the motor, and secure all components before powering the unit.
The guide also describes normal operation, wind‑direction adjustment, timer settings, and safety precautions such as keeping the fan away from heat sources and preventing finger injuries. Maintenance tips for cleaning and lubricating the motor are included. This manual is written in Japanese.
| Voltage | AC 110 V / 60 Hz |
|---|---|
| Power Consumption | 53 W (SK‑B14LT), 60 W (SK‑A16LT) |
| Wind Speed | ≥185 m/min (SK‑B14LT), ≥220 m/min (SK‑A16LT) |
| Air Flow | ≥40 m³/min (SK‑B14LT), ≥53 m³/min (SK‑A16LT) |
| Timer Setting | 3 hours |
| Power Cord Length | 1.8 m |
| Weight | 5.4 kg (SK‑B14LT), 5.9 kg (SK‑A16LT) |
| Net Weight | 8.7 kg (SK‑B14LT), 9.2 kg (SK‑A16LT) |
| Dimensions (W×D×H) | 770 mm × 1110 mm × 465 mm (SK‑B14LT), 800 mm × 1135 mm × 465 mm (SK‑A16LT) |
Follow the illustrated order, ensuring the front and rear nets are correctly installed and all screws are tightened before powering the fan.
Rotate the left‑right adjustment knob to change the angle of the airflow as needed.
Do not place the fan near open flames or high‑temperature sources, keep it away from children, and avoid inserting fingers or objects into the blades.
Turn off and unplug the fan, remove the front net and blades, clean with a soft cloth and mild water, then dry and apply a small amount of lubricant to the motor shaft.
