This manual explains how to assemble the SK-PF10(G) fan, including attaching the legs to the base, fixing the rear and front nets, and securing all bolts. Detailed diagrams show the correct order of parts and the direction for tightening fasteners.
Operating instructions cover turning the fan on and off, selecting low, medium, or high speed, and using the wind‑control button. Safety guidelines warn against using the fan near gas flames, in wet areas, or where children could insert objects, and outline emergency steps if the fan overheats or the power cord is damaged. Maintenance tips include cleaning with a soft cloth, avoiding solvents, and lubricating the rotating shaft once a year. This manual is written in Chinese.
| Voltage | 110V 60Hz |
|---|---|
| Power Consumption | 33W |
| Weight | 1.8 kg |
Attach the legs to the base, then fix the rear net and front net in the order shown, tightening the screws as indicated.
Press the adjustment key to select low, medium, or high wind speed.
Do not use the fan near gas flames, in wet areas such as bathrooms, or where children could insert objects; keep it away from windows and flammable materials.
Lubricate the rotating shaft at least once a year.
