The AI-517/517P is a modular temperature controller that supports multiple thermocouple and resistance sensor types, with a resolution of 0.01 °C and an input voltage range of 100‑240 VAC or 24 VDC. It features an AI‑based PID algorithm with auto‑tuning and a user‑editable interface, including password protection and customizable panels.
The manual covers hardware configuration, module installation (up to five modules), wiring diagrams, panel descriptions, display states, parameter tables, special functions, and program control for the AI‑517P variant. Detailed instructions are provided for setting time segments, set‑point values, and multi‑curve program sequencing. This manual is written in Chinese.
| Temperature resolution | 0.01 °C |
|---|---|
| Input voltage range | 100‑240 VAC or 24 VDC |
| Maximum modules | 5 |
| Supported sensor types | Multiple thermocouples and resistance sensors |
| Panel size A | 96 mm × 96 mm |
The controller can accommodate up to five optional modules.
It operates from 100‑240 VAC or from a 24 VDC power supply.
The device provides a resolution of 0.01 °C.
