KNIEL CÜ 5.2 is 19inch 3U 10W single output linear regulated power supply, with rated output voltage 5V and rated output current 2A.
The KNIEL CU 5.2 is a linearly regulated 10 W power supply with a single 5 V, 2 A output. It features a front‑panel design, optional jumpers for voltage range adjustment, and a compact size of 25 mm × 162 mm.
The datasheet lists detailed electrical characteristics such as >32 % efficiency, <5 mV load‑step voltage deviation, input voltage 115‑230 V (adjustable by ±10 %), and protection features including overload and over‑voltage protection. Operating temperature ranges from –25 °C to +70 °C and the unit weighs approximately 1 kg.
| Output Voltage | 5 VDC |
|---|---|
| Nominal Output Current | 2 A |
| Efficiency | >32 % |
| Input Voltage Nominal | 115 V‑230 V |
| Weight | 1 kg |
The output voltage is 5 VDC.
The nominal output current is 2 A.
It accepts a nominal input voltage of 115 V to 230 V, with an adjustable range of ±10 %.
The efficiency is greater than 32 %.
