This file is the instruction manual for the GDZ3.5-1 Q/XG J0520-203 washing machine
This manual provides the safety guidelines, installation steps, operating instructions and maintenance procedures for the Haier GDZ3.5-1 drum‑exhaust clothes dryer. It includes a specifications table, part identification, and troubleshooting tips.
The dryer must be installed on a level, stable surface with a 10‑15 cm clearance from the wall, connected to a dedicated 220 V 50 Hz power source, and used only in dry, well‑ventilated indoor locations. This manual is written in Chinese.
| Rated voltage / frequency | 220 V 50 Hz |
|---|---|
| Rated input power (high / low) | 1100 W / 670 W |
| Fuse rated current | 10 A |
| Maximum load capacity | 3.5 kg |
| Dimensions (W × D × H) | 630 mm × 425 mm × 685 mm |
| Net weight | 23 kg |
| Hot‑air timer | 220 min (incl. 20 min cooling) |
| Cold‑air timer | 60 min |
Connect the dryer to a 220 V, 50 Hz power supply.
The dryer can handle up to 3.5 kg of laundry per cycle.
