The product is Toshiba's XQB65-0566 model washing machine. This product has the characteristics of fast washing speed and high washing cleanliness, and also has anti-mildew function
This manual provides safety warnings, installation steps, and operating instructions for the Haier XQB65-0566 fully‑automatic washing machine. It includes guidance on connecting power, water inlet and drain hoses, adjusting the machine level, and proper use of detergents.
The document also contains a troubleshooting guide, specifications table, and after‑sales service information, including warranty terms and contact details for Haier service centers in China. This manual is written in Chinese.
| Water level / water volume | 1/21 L, 2/27 L, 3/32 L, 4/37 L, 5/42 L, 6/47 L, 7/51 L, 8/56 L |
|---|---|
| Inlet water pressure | 0.03‑0.78 MPa |
| Rated washing capacity | 6.5 kg |
| Washing noise | 57 dB(A) |
| Spin (de‑water) noise | 67 dB(A) |
The power plug must be inserted into a single‑phase 220 V AC socket with reliable grounding.
No. The manual advises not to use water above 50 °C.
Tilt the machine forward, remove the front cover with a screwdriver, then reposition the drain pipe as shown in the step‑by‑step instructions.
