This manual covers the basic operation of the Sampo DV-RH680 DVD recorder, including how to load discs, navigate menus, and use recording functions. It also describes the required power supply, safety precautions, and recommended environmental conditions.
Technical specifications are listed, such as power consumption, dimensions, weight, and supported video/audio formats. Connection diagrams for S‑Video, component video, and audio inputs are provided, along with wiring guidelines for proper installation.
| Input voltage | AC100‑240 V, 50/60 Hz |
|---|---|
| Dimensions (W×D×H) | 430 × 306 × 69 mm |
| Operating temperature | +5 °C to +40 °C |
The recorder operates on an AC input voltage of 100‑240 V at 50/60 Hz.
The recorder measures 430 mm wide, 306 mm deep and 69 mm high.
It can operate between +5 °C and +40 °C.
