This document describes the features and characteristics of the e- ALI S plasma display, including 3.15 million dot matrix high-density display, screen peak brightness of 1000cd/m2, high color temperature of 15000K, and long life of 60000 hours.
The e-ALIS 55PD5000TC is a 55‑inch LCD display offering a native resolution of 1366 × 768 pixels, high brightness of 1000 cd/m² and a wide color temperature range up to 15000 K. It supports multiple video inputs such as DVI‑D, DVD‑D, HDMI (HD Ready) and provides audio enhancement features like TruSurround and Trubass.
Technical data include a contrast ratio of 60000:1, an aspect ratio of 16:9, power consumption of 12 W per unit (12 W × 2), a weight of 63.5 kg and overall dimensions of 1394 × 857 × 105 mm. The panel also offers various connector options and complies with standard video formats (NTSC, PAL, 720p/1080i). This manual is written in Chinese.
| Resolution | 1366 × 768 |
|---|---|
| Brightness | 1000 cd/m² |
| Color Temperature | 15000 K |
| Video Input Interfaces | DVI‑D, DVD‑D, HDMI (HD Ready) |
| Audio Enhancement | TruSurround / Trubass |
| Dimensions (W × H × D) | 1394 mm × 857 mm × 105 mm |
The display has a native resolution of 1366 × 768 pixels.
It provides a brightness of 1000 cd/m².
The panel supports DVI‑D, DVD‑D and HDMI (HD Ready) inputs.
