The document describes the RT14 series cylindrical cap fuse, including its rated voltage of 380 V, rated current options (20 A, 32 A, 63 A), and compliance with GB 13539 and IEC 60269 standards. It also lists the supported base types and mounting dimensions for various models.
Technical data such as dimensions, power loss, and breaking capacity are presented in tables, along with diagrams showing how the fuse bases fit with the fuse bodies. The manual includes instructions for ordering parts and notes on substitution with compatible models. This manual is written in Japanese.
| Frequency | 50 Hz AC |
|---|---|
| Standards | GB 13539, IEC 60269 |
It complies with GB 13539 and IEC 60269.
