SGS210 GPS receiver is a single-frequency high-precision receiver for static measurement. Its antenna, OEM board, liquid crystal screen and collector contain chips from foreign famous manufacturers. It has stable performance, simple operation and convenient carrying. It is suitable for various construction units and measurement departments to do secondary and below-grade control measurement, line measurement, and also can be used for secondary and below-grade deformation monitoring.
The SGS210 GPS receiver is a high‑precision, portable device designed for surveying and construction applications. It provides 12 channels (L1 C/A + carrier phase) and supports both static and kinematic positioning.
The manual describes the main features, interface specifications, operating temperature ranges, power consumption, and step‑by‑step operating procedures, as well as a troubleshooting guide for common issues. This manual is written in Chinese.
| Channels | 12 (L1 C/A + carrier phase) |
|---|---|
| First fix time | <45 s |
| Re‑acquisition time | <3 s |
| Static positioning accuracy | 5 mm + 2 ppm·D |
| Kinematic positioning accuracy | 10 mm + 2 ppm·D |
| Interface | RS‑232C serial, 9600/19200 bps |
| Power consumption | 4 W |
| Receiver operating temperature | -20 °C ~ +55 °C |
| Antenna operating temperature | -30 °C ~ +65 °C |
Check that the antenna is properly connected and that the environment provides sufficient satellite visibility; the device may need to re‑initialize.
The first fix is achieved in less than 45 seconds under normal conditions.
The receiver consumes approximately 4 W during operation.
