This manual covers the DocuPrint 305’s performance specifications, including printing speeds, resolution, and paper handling capacities. It also details supported interfaces, power requirements, and maintenance information.
Key features such as fast warm‑up (10 s), first‑page output (5.2 s), high‑resolution printing up to 2400 dpi, and energy‑saving modes are described, along with instructions for network configuration and duplex printing. This manual is written in Chinese.
| Print speed (A4) | 20‑30 pages/min |
|---|---|
| Duplex speed | 13‑21 pages/min |
| Warm‑up time from sleep | 10 seconds |
| First‑page output time | 5.2 seconds |
| Processor | PowerPC 603e‑266 MHz |
| Standard / Maximum memory | 64 MB / 576 MB |
| Hard‑disk capacity | 20 GB |
| Monthly duty cycle | 100 000 pages |
| Paper tray 1 capacity | 150 sheets |
| Paper tray 2 capacity | 250‑550 sheets |
| Maximum paper capacity | 1500 sheets |
| Power supply | 220‑240 V, 50/60 Hz (also 110 V) |
| Maximum power consumption | 1100 W |
| Dimensions (W×D×H) | 505 mm × 376 mm × 390 mm |
| Weight | 22 kg |
The first page is output in 5.2 seconds.
Warm‑up from sleep takes about 10 seconds.
It supports RS232C, IEEE1284, USB 2.0, and Ethernet 100Base‑TX/10Base‑T.
The printer is rated for up to 100 000 pages per month.
