This document is the manual of ZL30J drive axle, which introduces the basic structure and working principle of the drive axle, as well as the usage methods.
The ZL30J drive bridge, produced by Jiangxi Fenyi Drive Bridge Co., Ltd, consists of a bridge housing, main transmission, half‑shafts, wheel‑side planetary reducer, and disc brake. Its planetary reducer and dual spiral bevel gears change power direction, reduce speed, and increase torque before delivering power to the driven wheels.
The manual is organized into chapters covering the basic structure and working principle, installation and use, periodic technical maintenance (levels 1‑3), detailed spare‑parts lists, and common fault troubleshooting with causes and corrective actions. This manual is written in Chinese.
| Total transmission ratio | 20.74 |
|---|---|
| Maximum input torque | 2110 Nm |
| Braking torque | 1755 Nm (approx.) |
| Overall length (single bridge) | 2119 mm |
| Wheelbase (single bridge) | 1726 mm |
| Bridge weight | 715 kg |
| Center distance of connecting holes | 865 mm |
