The manual outlines important safety measures for installing the micro shield, including disconnecting power before cleaning, using only approved accessories, and protecting against lightning and fire hazards. It also warns against improper mounting, exposure to corrosive liquids, and unauthorized repairs.
Installation steps cover opening the top cover, loosening and removing the camera slide screws, fixing the camera with the supplied imperial‑size screws, adjusting the camera and lens position, and connecting power and video cables as shown in the wiring diagram. The guide lists optional accessories such as fans and heaters, provides a parts list, and includes technical specifications for voltage, power, temperature range, and dimensions. This manual is written in Chinese.
| Input voltage | AC24V, DC12V |
|---|---|
| Input power | 10W |
| Operating temperature | -25°C to 49°C |
| Maximum camera + lens dimensions | 150 × 63 × 63 mm |
| Material | ABS |
| Window size | 68 mm |
Disconnect the power, do not use liquid or spray cleaners, and wipe with a damp cloth.
Fans, heaters, and other accessories can be selected according to user needs to lower internal temperature.
