The 52 series network camera is an embedded digital monitoring product that integrates traditional analog cameras and network video servers. It adopts a high-performance SOC (ARM+DSP) designed specifically for multimedia processing, combined with a high-performance operating system and audio and video compression algorithms, making the image transmission smoother and the display clearer and more delicate; The built-in WEB server can enhance the performance of the traditional monitoring system and make it easy to publish safe monitoring images on the local area network or the Internet.
This guide introduces the 52 Series network cameras, which combine a traditional analog camera with an embedded video server. It outlines the main features such as H.264 video compression, PTZ control, alarm I/O, and Wi‑Fi connectivity, and explains the intended applications ranging from banking to industrial monitoring.
The document is organized into sections covering safety precautions, hardware installation, interface description, parameter configuration via web browser or client software, WAN access (PPPoE, DHCP, etc.), and a FAQ. Appendices list the default network parameters and instructions for making Ethernet cables. This manual is written in Chinese.
| Video compression | H.264 |
|---|---|
| Supported resolutions | 720P, D1, 2CIF, CIF, QCIF |
| Network interface | 10M/100M auto‑negotiation Ethernet |
| Power input | DC 12 V / 1.0 A (waterproof model 12 V/3 A) |
| Alarm inputs | 1 signal‑type input |
| Alarm outputs | 1 switch‑type output |
| Audio input | Ain connector |
| Wi‑Fi support | Wireless transmission with WEP/WPA/WPA2 encryption |
The camera ships with IP 192.168.1.19, subnet mask 255.255.255.0, gateway 192.168.1.1, and default ports such as Web 80, RTSP 554, and DDNS disabled.
It provides one signal‑type alarm input and one switch‑type alarm output.
