DX-11 Signal Relay User Manual

DX-11 type signal relay is used in DC operation protection line as action indicator.

DX-11 Signal Relay User Manual - cover page
Brand
DX-11
Category
Other
Document type
User Manual
Language
Japanese
Pages
2
File format
PDF
File size
989 KB
Published
15 March, 2012
Updated
01 October, 2023
MD5 checksum
A181C466E6A07361716D9D1BFE550DDE
PDF
DX-11 Signal Relay User Manual PDF

About this manual

This manual lists the main electrical parameters of the DX-11 signal relay, including rated current, voltage, and power consumption. It also details the physical size and mounting references for proper installation.

Installation guidelines describe the front and rear connection methods, showing the recommended wiring configurations and mounting dimensions for the device. This manual is written in Japanese.

What's inside

  • Electrical specifications
  • Physical dimensions and mounting
  • Wiring connection methods

Specifications

Rated current0.025 A DC

Frequently asked questions

What is the rated current of the DX-11 relay?

The relay is rated for a current of 0.025 A DC.

What are the installation dimensions of the DX-11 relay?

The front panel dimensions are approximately 55 mm by 38 mm.
