JS14A series time relay is suitable for AC 50Hz, rated control power supply voltage 380V and below or DC 24V and below control circuit as a delay element, according to the predetermined time to connect or disconnect the circuit.
This manual describes the technical parameters of the JS14A series time relay, including operating modes, voltage ratings, delay accuracy and selectable delay ranges. It also lists the available connection types such as device‑type, panel‑type and external‑type.
Installation information covers the physical dimensions of the relay for different mounting styles and provides the maximum height values for device‑type, panel‑type and external‑type installations. This manual is written in Japanese.
| Rated Voltage | AC 36V, 110V, 127V, 220V, 380V; DC 24V |
|---|---|
| Delay Range | 0.5 s – 1800 s (selectable) |
The relay can be installed as a device‑type, panel‑type, or external‑type, each with its own set of connection terminals.
